Automatic Compression/Flexural Testing Machine

Send Inquiry

Request To Call Back

Automatic Compression/Flexural Testing Machine

Price 1.00 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Automatic Compression/Flexural Testing Machine Specification

Power Supply
220240 V, 50 Hz, Single Phase

Number of Specimens
1 per cycle

Automation Grade
Fully Automatic

Display Type
Digital LCD / Touch Screen

Temperature
Ambient to 40C

Application
Compression and flexural strength testing of concrete specimens

Interface Type
USB/Ethernet (for data transfer)

Equipment Type
Automatic Compression/Flexural Testing Machine

Resolution
0.1 kN

Specimen Size
Cubes: 150x150x150 mm, Cylinders: 150x300 mm, Prisms: 100x100x500 mm

Test Range
Up to 3000 kN (as per model)

Features
Overload protection, Data storage, Auto-calibration

Humidity
Up to 90% RH (non-condensing)

Mounting Type
Floor Mounted

Port Size
Standard as per IS/ASTM specifications

Response Time
<1 second

Operating Voltage
220-240 V, 50 Hz

Hardness
Machine frame surface hardened

Measuring Range
0100% of machine capacity

Frequency
50 Hz

Max Height
400 mm (specimen limit)

Accuracy
1% of indicated load

Usage
Laboratory / Industrial

Capacity
1000 kN, 2000 kN, 3000 kN

Machine Weight
Approx. 350 kg

Test Speed
0.01 9.99 mm/min (variable)

Test Width
150 mm

Test Stroke
Up to 100 mm

Control Mode
Automatic / PLC Controlled

Automatic Compression/Flexural Testing Machine Trade Information

Minimum Order Quantity
1 Piece

FOB Port
Ahmedabad

Payment Terms
Letter of Credit (L/C), Cash Against Delivery (CAD), Telegraphic Transfer (T/T), Cash in Advance (CID), Cheque, Cash Advance (CA)

Supply Ability
100 Pieces Per Year

Delivery Time
4 Week

Sample Policy
Contact us for information regarding our sample policy

Packaging Details
Wooden Box With Strong Base

Main Domestic Market
All India

Certifications
ISO 9001 : 2015

About Automatic Compression/Flexural Testing Machine

Compliance With Following International Standards

EN 12390-4, ASTM C39, AASHTO T22, IS : 14858 (2000), BS : 1881

Salient Features

Works on 220-240 Volts, 50-60 Hz, Single phase, AC Supply.
Calibrated with an accuracy of ± 1%.
High accuracy and test repeatability.
Automatic Pace rate control
Automatic stress calculation and display
Automatic control unit for compression hydraulic testing frames
With the rapid-change platen system, the operator can quickly and easily mount a wide range of accessories for cylinder and cubes.
The test execution confirms to International Standards can be easily proved.
Aesthetic Design and attractive outer appearance
Powder coated body

Precision Testing with User-Friendly Automation

This machine simplifies concrete compression and flexural strength testing through its fully automatic, PLC-controlled operation. Intuitive Windows-based software and touchscreen controls make setting up and running tests straightforward. The system accommodates a variety of specimen types and sizes while delivering rapid, consistent results that comply with IS: 516 and ASTM standards.

Advanced Safety and Reliability Features

Designed with operator safety in mind, the equipment features an emergency stop, robust safety enclosure, overload protection, and auto-calibration functions. The heavy-duty, powder-coated steel frame provides durability and stability, while the low response time (<1s) and precise resolution (0.1 kN) ensure reliable and repeatable measurements. Ideal for heavy industrial and laboratory environments.

Comprehensive Data Management and Connectivity

Enjoy seamless data handling with built-in data storage capabilities, test report generation in CSV/PDF formats, and flexible USB/Ethernet interface options for data transfer. Optional remote monitoring via LAN/WiFi further enhances accessibility. The system generates comprehensive documentation for quality control, auditing, and compliance processes.

FAQs of Automatic Compression/Flexural Testing Machine:

Q: How does the Automatic Compression/Flexural Testing Machine ensure accurate and reliable results?

A: This machine utilizes a servo-controlled motor drive and advanced PLC automation to deliver consistent test speeds from 0.01 to 9.99 mm/min. It is calibrated according to IS: 516, features auto-calibration, and provides measurement accuracy within 1% of the indicated load with a fine resolution of 0.1 kN, ensuring dependable and precise results every time.

Q: What safety features are built into the testing machine?

A: The equipment is equipped with a robust safety enclosure to protect operators during testing, as well as an emergency stop button for immediate machine shutdown if required. Overload protection safeguards both users and specimens, and the powder-coated, hardened frame adds additional durability and operational safety.

Q: When should I calibrate or maintain this testing machine?

A: Although the device features auto-calibration, its recommended to verify calibration regularly based on internal QC schedules or after heavy usage or major maintenance. Routine maintenance, including inspection of hydraulic and electronic systems, will help ensure optimal performance and longevity.

Q: Where can this machine be installed and used?

A: This model is designed for laboratory and industrial environments, and it is suitable for installation in facilities across India and abroad. Its floor-mounting design requires stable ground and access to a 220240 V, 50 Hz single-phase power supply. It is engineered to operate within ambient temperatures up to 40C and up to 90% non-condensing humidity.

Q: What types and sizes of specimens can the machine test?

A: The machine is designed to handle a variety of concrete specimens, including cubes (150x150x150 mm), cylinders (150x300 mm), and prisms (100x100x500 mm). It can test one specimen per cycle, with a testing width of 150 mm and a maximum stroke of 100 mm, supporting capacities of 1000, 2000, or 3000 kN based on the chosen model.

Q: How is test data managed and exported from the system?

A: Test results are digitally displayed and can be automatically stored within the machine. Reports can be generated in .csv or .pdf formats for easy documentation and sharing. The USB/Ethernet interface, along with optional LAN/WiFi connectivity, facilitates straightforward data transfer and remote monitoring.

Q: What are the benefits of using this fully automatic compression/flexural testing machine?

A: This equipment increases efficiency and standardizes testing in line with IS/ASTM protocols. Fully automated operation minimizes human errors, while safety features reduce risk. Comprehensive test data generation, secure data storage, and remote connectivity support robust quality assurance and compliance in research, production, and QA laboratories.
