Unconfined Compression Tester-Digital

Price 1.00 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Unconfined Compression Tester-Digital Specification

Humidity
Up to 95% RH (Non-condensing)

Response Time
<1 sec

Port Size
25 mm

Specimen Size
38 mm dia x 76 mm height

Measuring Range
0 - 2 kN

Operating Voltage
220 V

Interface Type
RS232/USB

Hardness
Body: Mild Steel, Table: Hardened Steel

Max Height
400 mm

Automation Grade
Semi-Automatic

Resolution
1 N

Application
Testing unconfined compressive strength of soil specimens

Frequency
50 Hz

Features
Automatic & Manual Operation, Data Storage

Display Type
Digital LED/LCD

Gas Pressure
Ambient (Not Applicable)

Number of Specimens
1 per test

Equipment Type
Unconfined Compression Tester

Temperature
0C to 50C

Mounting Type
Bench Top

Power Supply
220 V AC, 50 Hz

Test Range
Up to 2000 N

Accuracy
1%

Usage
Laboratory/Field Soil Testing

Capacity
2 kN

Machine Weight
Approx. 40 kg

Test Speed
1 mm/min - 5 mm/min (adjustable)

Test Width
150 mm

Test Stroke
110 mm

Control Mode
Digital, Microprocessor Based

Data Output
PC Compatible

Environment Compatibility
Operation in Laboratory and Mobile Setup

Overload Protection
Electronic Cut-off

Frame Construction
Heavy Duty Powder Coated Steel

Rate of Deformation Measurement
Digital Encoder

Calibration
Factory Calibrated & User Calibratable

Platen Material
Polished Stainless Steel

Load Measurement
Precision Load Cell

Accessories
Specimen Mould, Trimmer, Sample Extractor

Manufacturer Warranty
1 Year

Unconfined Compression Tester-Digital Trade Information

Minimum Order Quantity
1 Piece

FOB Port
Ahmedabad

Payment Terms
Cash Against Delivery (CAD), Cash Advance (CA), Letter of Credit (L/C), Telegraphic Transfer (T/T), Cash in Advance (CID), Cheque

Supply Ability
100 Pieces Per Year

Delivery Time
4 Week

Sample Policy
Contact us for information regarding our sample policy

Packaging Details
Wooden packing with strong base

Main Export Market(s)
Australia, South America, Middle East, Asia, Africa

Main Domestic Market
All India

Certifications
ISO 9001 ; 2015

About Unconfined Compression Tester-Digital

Compliance with following International Standards

BIS 2720 (Part 10)

Specification

Type of Pumping	Electrical
Loading Range	2000KN
Least Count	1 KN
Max. Clearance Between Platen	370mm
Max. Clearance Between Side Platen	340mm
Platen Size	220 mm sq.
Piston Stroke	215.00 mm

Robust Frame and Precision Engineering

Manufactured with a heavy-duty powder-coated steel frame and polished stainless steel platens, this Unconfined Compression Tester ensures long-term durability and reliable performance. Its precision load cell delivers exceptional measurement accuracy, while overload protection safeguards both equipment and samples during testing.

Digital Control and Versatile Operation

Equipped with a microprocessor-based digital control system, the machine features adjustable test speeds and both automatic and manual operation for tailored test procedures. Data can be outputted directly to a PC via RS232 or USB for streamlined analysis and reporting.

Adaptable to Laboratory and Field Use

Designed for flexibility, this tester operates efficiently in both controlled laboratory settings and mobile field setups. With a compact, bench-top design and a 1-year manufacturer warranty, it is ideal for soil testing across diverse environments in India.

FAQs of Unconfined Compression Tester-Digital:

Q: How does the Unconfined Compression Tester-Digital measure and display test data?

A: It uses a precision load cell to measure force, and a digital encoder to capture deformation rates, both of which are processed by a microprocessor and displayed on a digital LED or LCD screen. Data can be exported to a PC via RS232 or USB interface.

Q: What is the process for calibrating this tester, and who can perform it?

A: The tester comes factory calibrated for immediate use, but users can easily recalibrate it as needed using the provided instructions to ensure continued accuracy over time.

Q: When should I use this equipment for soil testing?

A: This tester is ideal for use whenever unconfined compressive strength needs to be determined, particularly during soil characterization in laboratory or mobile field settings for construction or geotechnical projects.

Q: Where can the Unconfined Compression Tester-Digital be operated?

A: Thanks to its robust design and portability, the tester is suitable for laboratory benches and mobile setups, accommodating environments with temperatures from 0C to 50C and humidity up to 95% RH (non-condensing).

Q: What accessories are included with the tester for sample preparation?

A: The tester comes equipped with a specimen mould, a trimmer, and a sample extractor to aid in preparing and handling soil samples for accurate testing results.

Q: How does the overload protection feature work?

A: The system includes an electronic cut-off mechanism that automatically halts operation if loads above the machines threshold are detected, ensuring safety of both user and equipment.

Q: What benefits does digital control offer during testing?

A: Digital control enables precise test speed adjustment, real-time data monitoring, and easy switching between automatic and manual operation, resulting in consistent and reliable testing outcomes.
